美国Catphan500CT性能测试医疗模体
产品编号:2013627105853
产品描述:美国Catphan 500 CT性能测试模体已得到全球知名CT生产公司的认同,都用它来标示CT机的成像性能。该模体较依据AAPM 1977年1号报告生产加工的注水模体有很多优点:因是固体模体,没有漏水的问题;储运箱能当模体支架,模体能探出扫描床外;低对比度分辨力模体由同一种物质不同密度材料制成等。
厂家:The Phantom Laboratory

|
|
产品介绍
医疗模体:

模体用来检测医院的CT性能,由塑料制成,Catphan500, Catphan600, Catphan5700, CTP500, CTP600, CTP700等. 另外一个是医院的磁共振性能检测模体,完全使用有机玻璃制成,也有两个型号,其中的圆柱形,就是Magphan® SMR170,厂家是美国模体实验室。
功能:Phantomlab与物理学家兼哲学家Goodenough, Ph.D.,共同努力发展了Catphan®模体。新型的Catphan®模体设计是基于医疗成像仪器方面二十多年的科学研究和临床经验。该种模体可以应用于轴向和螺旋CT扫描成像系统的各种操作评价以及质量保证系统。
不同的模块组成了Catphan®模体,这些模块尚可适用于连续20cm空间。为了在Catphan®424中使用水容器,所有Catphan®组件都是由Solid-cast材料构成。Solid-cast结构可以降低材料的吸水性和水浴模体相关的露水问题。
包括Catphan®500在内共有三种基本Catphan®模体。Catphan®是为螺旋CT扫描而殊设计的。
包括Catphan®模体的选择性测试模块及其标
准,经常被用于进行许多实验测量。包括以下
一、参数的评估:
扫描几何学(层宽和灵敏度曲线)
高分辨率(高至20线对/厘米)
体模定位验证
病人定位系统验证
supra-slice低对比度灵敏度
subslice低对比度灵敏度
空间均匀性
扫描增量
CT系统噪声(精度)
圆对称性
灵敏度(线性)
象素(矩阵)尺寸
动态扫描
X、Y、Z轴的点扩散函数和调制传递函数(MTF)
- patient alignment system check
- low contrast sensitivity
- comparative subslice and supra-slice low contrast sensitivity
- spatial uniformity
- scan incrementation
- noise (precision) of CT systems
- circular symmetry
- sensitometry (linearity)
- pixel (matrix) size
- point spread function and modulation transfer function (MTF) for the x, y, and z axes
Catphan® 700(Stock CTP700) - Complete Catphan® including housing and case, equipped with the following test modules:
CTP682 - Geometry sensitometry and point source module
CTP714 - 30 line pair high resolution module
CTP515 - Subslice and supra-slice low contrast
CTP721 - Wave insert
CTP723 - Bead blocks
CTP712 - Uniformity section
|

|

|
Catphan 600®(Stock CTP600) - Complete Catphan® including housing and case, equipped with the following test modules:
CTP404 - Slice width, sensitometry and pixel size
CTP591 - Bead Geometry module
CTP528 - 21 line pair high reslution and point source
CTP515 - Subslice and supra-slice low contrast
CTP486 - Solid image uniformity module
Catphan® 500(Stock CTP500) - Complete Catphan including housing and case, equipped with the following test modules:
CTP401 - Slice width, sensitometry and pixel size
CTP528 - 21 line pair high resolution and point source
CTP515 - Subslice and supra-slice low contrast
CTP486 - Solid image uniformity module
Catphan® 412(Stock CTP412) - Complete Catphan including housing and case, equipped with the following test modules:
CTP401 - Slice width, sensitometry and pixel size
|

|
CTP445 - MTF module with bead point source
CTP446 - 20 line pair high resolution
CTP263 - Low contrast
CTP486 - Solid image uniformity module
Catphan® 424(Stock CTP424) - Complete Catphan including housing and case, equipped with the following test modules:
CTP401 - Slice width, sensitometry and pixel size
CTP445 - MTF module with bead point source
CTP446 - 20 line pair high resolution
CTP263 - Low contrast
CTP422 - Liquid bath
Catphan® 440(Stock CTP440) - Complete Catphan including housing and case, equipped with the following test modules:
CTP401 - Slice width, sensitometry and pixel size
CTP592 - Low and high contrast resolution module
|

|
产品编号 |
Description |
CTP700 |
Complete Catphan® 700 including housing, case, and test modules |
Includes the following: CTP682-Geometry sensitomety and point source module, CTP714-30 line pair high resolution module, CTP515- Subslice and supra-slice low contrast, CTP721 Wave insert, CTP723-Bead blocks, CTP712 Uniformity section |
CTP600 |
Complete Catphan® 600 including housing, case, and test modules |
Includes the following: CTP404-Slice width, sensitometry and pixel size, CTP591-Bead geometry module, CTP528-21 line pair high resolution and point source, CTP515-Subslice and supra-slice low contrast, CTP486-Solid image uniformity module |
CTP500 |
Complete Catphan® 500 including housing, case, and test modules. Includes the following:CTP401 Slice width, sensitometry and pixel size, CTP528-21 line pair high resolution and point source, CTP515-Subslice and supra-slice low contrast, CTP486-Solid image uniformity module |
CTP412 |
Complete Catphan® 412 including housing, case, and test modules. Includes the following:CTP401-Slice width, sensitometry and pixel size, CTP446-20 line pair high resolution, CTP263-Low Contrast, CTP486-Solid image uniformity module |
CTP424 |
Complete Catphan® 424 including housing, case, and test modules. Includes the following:Slice width, sensitometry and pixel size, CTP445-MTF module with bead point source, CTP446-20 line pair high resolution, CTP263-Low contrast, CTP422-Liquid bath. |
CTP440 |
Complete Catphan® 440 including housing, case, and test modules. Includes the following:CTP401-Slice width, sensitometry and pixel size, CTP592-Low and high contrast resolution module |
CTP401 |
Slice width, sensitometry and pixel size module |
CTP404 |
Slice width, sensitometry and pixel size module |
CTP445 |
MTF Module with bead point source |
CTP446 |
20 line pair high resolution module |
CTP528 |
21 line pair high resolution and point source module |
CTP422 |
Liquid Bath |
CTP486 |
Solid image uniformity module |
CTP263 |
Low Contrast Module |
CTP515 |
Sub-slice and supra-slice low contrast module |
CTP592 |
Low and high contrast resolution module |
CTP591 |
40mm bead geometry module |
CTP501 |
16cm housing and mount with modules CTP591 & CTP486-3 |
CTP295 |
Liquid bath scan alignments inserts |
CTP291 |
Liquid bath acrylic LSF inserts |
CTP299 |
Teflon annulus |
CTP539 |
30cm OD uniformity material body annulus |
CTP540 |
35cm OD uniformity material body annulus |
CTP650 |
38cm OD uniformity material body annulus |
CTP579 |
25-35cm oval OD uniformity material body annulus |
CTP651 |
30-38cm oval OD uniformity material body annulus |
CTP599 |
45-55cm oval OD uniformity material body annulus |
CTP326 |
32cm OD acrylic body annulus |
CTP541 |
16cm OD housing and mount |
CTP536 |
35cm center off-center housing |
CTP553 |
32cm Acrylic Dose Phantom |
CTP554 |
16cm Acrylic Dose Phantom |
CTP558 |
Dose Phantom Set includes 16cm & 32cm |
|
|
AutoQALite Software for use with the CatPhan CT Phantoms. |
|
An updated Windows program to the original PC/AutoQA for CT. This update provides expanded image processing capacity for up to 96 images in a data set with a comprehensive trend analysis feature.
PROCESSING FEATURES
CT AutoQA Lite™ can be configured with various vendor phantoms including ACR and all Catphan® models.
CT AutoQA Lite™ is DICOM3.0 compatible, a DICOM Storage Provider (SCP) Application license is provided.
CT AutoQA Lite™ provides the same analysis function as the original PC/AutoQA (DOS) version.
- Pixel Size – test verifies the expected pixel size based on the display field of view and the reconstruction matrix size from the measured set of four calibration pins positioned at a known physical location as specified in the Catphan® section CTP401 and CTP404.
|
|
